Rimart系列

1.室内外压铸铝出租系列，轻薄。

2.可弯曲拼接。

3. 3500*500mm /1000*500mm 复杂组合。

4.室内和室外保持相同的面板设计。

5.满足平面也弧拼接.弧在0-15度之间。

6.LCD显示屏让你轻松控制屏幕状态。

7.精密的压铸工艺使接头无缝。

技术参数

Pixel Pitch	2.6mm	2.9mm	3.91mm	4.81mm
LED Configuration	SMD1515	SMD2121(SMD1921)	SMD2121(SMD1921)	SMD2121(SMD1921)
Pixel Density	147456dot/m2	112896dot/m2	65536dot/m2	43264dot/m2
Module Size	250x250×15mm	250x250×15mm	250x250×15mm	250x250×15mm
Module Resolution	96x96dot	84x84dot	64x64dot	52x52dot
Cabinet Size	500x500x81mm
Cabinet Resolution	192x192dot	128x128dot	104x104dot	80x80dot
Cabinet Weight	7.5kg/outdoor 8k
IP Rating ( front/back)	IP43/IP65
Brightness	1200-1500nit/m2	1200-1500nit/m2 4500-5000nit/m2	1200-1500nit/m2 4500-5000nit/m2	1200-1500nit/m2 4500-5000nit/m2
Viewing Angle (H/V)	140°/140°(outdoor 120°/120°)
Viewing Distance	＞3m	＞3m	＞4m	＞5m
Gray Scale	14bit
Max.Power Consumption	620 W/m2	620 W/m2	550 W/m2	550 W/m2
Ave.Power Consumption	180 W/m2	180 W/m2	160 W/m2	160 W/m2
Refresh Rate	≥2880Hz
Environment	INDOOR/Outdoor
Control Mode	Synchronous display with control PC by DVI
Support Input	Composite,S-Vido,Component,VGA,DVI,HDMI,HD_SD
Operation Power	AC110~ 240V, 50/60Hz
Operating Temperature	0°C~40°C(work) , - 20°C~60°C(store)
Operating Life	≥100,000hours
